Micromatic Hydraulic Cylindrical OD & ID Grinders - RSS Grinders & Automation Inc.

Hydraulic-Driven Grinders

		ECO 200U
Swing diameter	mm	200
Admit between center	mm	400
Grinding wheel (dia x width)	mm	350 x 40
Wheel motor power	kW	3.7
Wheel speed	m/sec.	33
Work head speed	rpm	100-1000

ECO-200

		GCE 260/350
Swing diameter	mm	260/350
Admit between center	mm	500-1200
Grinding wheel (dia x width)	mm	400 x 50
Wheel motor power	kW	3.7
Wheel speed	m/sec.	33
Work head speed	rpm	56-630

		GCH 350/440
Swing diameter	mm	350/440
Admit between center	mm	800-1600
Grinding wheel (dia x width)	mm	500 x 100
Wheel motor power	kW	7.5
Wheel speed	m/sec.	33
Work head speed	rpm	28-300

GCHU440
